Adaptec 8885 8 Port 12GB/s SAS/SATA Raid Card

Operating System

Microsoft Windows

Red Hat Linux

SUSE Linux

Fedora

Debian Linux

Ubuntu Linux

Sun Solaris

FreeBSD

VMware ESXi



For a detailed list see ASK Answer ID 17318.





Benefits

               Ideal for 12Gb/s performance-hungry server and workstations platforms, without compromising proven Adaptec reliability



Customer Needs

               High I/O transaction and high bandwidth processing; solutions that reduce energy consumption and maintenance costs.



Key RAID Features

• Flexible Configuration: HBA Mode & Auto Volume Mode for automatic deployment

• Optimized Disk Utilization (Multiple Arrays per disk)

• Supports up to 256 SAS or SATA devices using SAS expanders

• Supported RAID levels: 0, 1, 1E, 5, 6, 10, 50, 60

• Support for native 4K sector SAS and SATA devices in addition to 512byte sector devices

• Hybrid RAID 1 & 10

• Quick initialization

• Online Capacity Expansion

• Performance modes: Dynamic, OLTP & Big Block ByPass

• Copyback Hot Spare

• Dynamic caching algorithm

• Native Command Queuing (NCQ)

• Background initialization

• Hot-plug drive support

• RAID Level Migration

• Hot spares - global, dedicated, and pooled

• Automatic/manual rebuild of hot spares

• SES and SAF-TE enclosure management

• Configurable stripe size

• S.M.A.R.T. support

• Multiple arrays per disk drive

• Dynamic sector repair

• Staggered drive spin-up

• Bootable array support

• Support for Tape Devices, Autoloaders

• MSI-X support for all device driver for all supported Operating Systems

• Secure boot support for the uEFI host bios

• USB image available, after shipping, on start.adaptec.com to boot maxView GUI from any USB device for enhanced GUI based setup and offline maintenance



Management Utilities

Software

• Adaptec maxView Storage Manager

• Web based GUI Management Utility

• OS Support: Windows, Linux, Solaris VMware

• Remote configuration, monitoring & notification

• Remote firmware updates

• SMI-S Support

• SMTP



ARCCONF

• Command Line Interface

• SMI-S support for VMware



Adaptec BIOS Configuration Utility (CTRL+A)

• BIOS level configuration utility

• Flashable BIOS support



Adaptec uEFI BIOS Configuration Utility

• HII based confi guration utility

• Flashable BIOS support



Data Transfer Rate

12Gb/s per port



Bus System Interface

8-lane PCIe Gen3



Form Factor

MD2 – Low Profile



Cache Memory

1024MB



Connector Configuration

Two internal mini SAS HD (SFF-8643), two external mini SAS HD (SFF-8644)



Package Contents

• Adaptec RAID 8885 adapter

• Additional low profile vented bracket





Physical Size

64mm x 167mm



Operating Temperature

0°C to 55°C* (with 200 LFM airflow)

Note: This Adaptec card contains a powerful RAID processor which requires adequate airflow to operate reliably. Please install this card only into server or PC chassis with recommended airflow (200 LFM). * Ambient temperature measured 1" away from the RAID processor



Operating Voltage

0.1A @ 3.3VDC 1.2A @ 12VDC



Regulatory Certification

CE, FCC, UL, C-tick, VCCI, KCC, CNS



Environmental Compliance

RoHS



Mean Time Before Failure (MTBF)

>700,000 hours at 40°C
